• If the leading-edge margin on the side 1 of the paper is too narrow, paper jams may occur.
• If the trailing-edge margin on the side 1 of the paper is too narrow, paper jams may occur when
printing on the back in duplex printing.
Paper feed direction
Leading-edge margin
Trailing-edge margin
CWY015
• This setting is not effective for paper fed from paper trays with custom paper presets. For such
paper, the value specified in [Image Position: Side1] in [Advanced Settings] takes precedence.
0102 Image Position: With Feed: Side 2
Adjust the image position (left and right) on side 2 along the feeding direction.
Press [ ] to shift the image position to the left (toward the bottom edge), or press [ ] to shift the position
to the right (toward the leading edge).
Paper feed direction
Top
Bottom
Left
(Trailing Edge)
Right
(Leading Edge)
CWY014
Setting Values
169
