• For details about which ICMP message types will be bypassed when setting [All ICMP Bypass] to
[Inactive], see Web Image Monitor Help.
Configuring the IPsec Policy
Click the [IPsec Policy List] tab on the IP security settings page to display the list of registered IPsec
policies.
Item Description
No. IPsec policy number.
Name Displays the name of the IPsec policy.
Address Settings Displays the IP address filter of the IPsec policy as below:
Remote address/Prefix length
Action Displays the action of the IPsec policy as "Allow", "Drop", or "Require
Security".
Status Displays the status of the IPsec policy as "Active" or "Inactive".
To configure IPsec policies, select the desired IPsec policy, and then click [Change] to open the "IPsec
Policy Settings" page. The following settings can be made on the "IPsec Policy Settings" page.
8. Configuring the Machine Using Web Image Monitor
340
