Ricoh SP C250DN

Print Area
The diagram below shows the area of the paper that the machine can print on.
Paper
DAC571
1
2
4
3
3
4
1. Print area
2. Feed direction
3. Approx. 4.2 mm (0.2 inches)
4. Approx. 4.2 mm (0.2 inches)
Envelope
4
1
2
3
3
3
DAC577
1. Print area
2. Feed direction
3. Approximately 10 mm (0.4 inches)
4. Approximately 15 mm (0.6 inches)
2. Loading Paper
52
