3.
Paper Output Guide Plate Home Position Sensor [A] (
×1).
Shift Roller Home Position Sensor
1.
Control board bracket (
page 16
).
2.
Shift roller home position sensor unit [A] (
×1,
×1,
×2).
1. Replacement and Adjustment
24
