Ricoh SR3130 - Stapler Displacement Motor

3. Shift motor unit [A] ( ×2, ×1, ×1).
4. Shift motor [A] ( ×2).
Stapler Displacement Motor
• When the finisher is inverted, be careful not to deform the frame.
1. Paper output cover (page 15).
1. Replacement and Adjustment
38
