32
Getting Started
1
Powering the Camera
Use the rechargeable lithium-ion battery D-LI92 that is provided with the camera.
1
Slide the battery cover lock as indicated by 1, and release the
lock.
2
Slide the release latch as indicated by 2, and open the battery
cover towards 3.
3
Using the side of the battery to push the battery lock lever in
the direction of 4, insert the battery with the PENTAX logo
pointing toward the lens.
Push the battery in until it is locked in place.
4
Close the battery cover, and slide the release latch in the
opposite direction indicated by 2.
Make sure that the yellow indicator cannot be seen and the cover is completely
closed.
Installing the Battery
If the battery is incorrectly oriented, malfunction may result.
Battery cover lock
Battery lock lever
Battery cover
Battery
Release latch
