S9922 3G/4G Router User Manual
RICON: Mobile Connect Tecnology
Parameter
Details
Operation

Interface
Network
Need to input network address
when “source type” selected as
“Static IP”.
Input distination address and
digits of subbet mask.
Format: A.B.C.D/M.
Source interface
Need to configure if “interface”
is selected. To select source
address of policy route.

modem

modem2
Select from DropDownList
Gateway type
To set the next hop address of
policy route.

Static IP

interface
DropDownList
Gateway
Need to input IP address when
“static IP” is selected for
“gateway type”.
Format: A.B.C.D/M.
Priority
Priority of policy route, the
lowerpriority No is, the higher
level priority is
Value area: [1,32000]
Step 5 Single click “save” icon to finish.
---END
5.6 VPN configuration
5.6.1 Overview
S9922 4G Router supports VPN (Virtual Private Network) including L2TP/PPTP/GRE/IPIP/IPSEC. What’s
more, it supports VPN OVER VPN, e.g. GRE over IPSec, IPSec over PPTP/L2TP/GRE/IPIP.
5.6.2 VPDN configuration
VPDN stands for Virtual Private Dial-up Networks. Now VPDN supports L2TP and PPTP
Step 1 Log on WEB GUI of S9922 4G Router.
