Riden RD6012P - APP Operation

声明：本说明书著作权归杭州睿登科技有限公司所有，未经允许任何单位或个人不得用于商业用途。
53
BA: sidebar
BQ: move the cursor to the left
BB: add device
BR: move the cursor to the right
BC: return
BS: set button
BD: more options
BT: screen brightness
BE: curve
BU: system temperature
BF: actual output voltage
BV: sync time
BG: actual output current
BW: data group quick call out
BH: actual output power
BX: battery voltage
BI:input voltage
BY: external sensor temperature detecting value
BJ: preset voltage value
BZ: accumulated output capacity
BK: preset current value
CA: accumulated output energy
BL: ON/OFF button
CB: device
BM: protection status indication
CC: device name
BN: keypad lock indication
CD: product SN number
BO: constant voltage/current status indicator
CE: product firmware version
BP: adjust wheel
2.2.3 APP Operation
2.2.3.1 Network Distribution
Connect Wi-Fi for the first time, please
insert the WiFi board to the right position, then
power on RD6012P, you will see the blue LED
blinks once. Set the communication interface to
WIFI, restart RD6012P, then place the RD6012P
and the mobile phone close to the 2.4G router
(the mobile phone must also be under the same
figure 16
