Riden RD6012P - APP Operation

声明：本说明书著作权归杭州睿登科技有限公司所有，未经允许任何单位或个人不得用于商业用途。
59
DF: actual output power
DT: accumulated output capacity
DG: input voltage measurement value
DU: accumulated output power
DH: preset voltage value
DV: model being connected
DI: preset current value
DW: product SN number
DJ: output ON/OFF button
DX: product firmware
DK: protection status indication
DY: switch current range
DL: battery status indication
DZ: main page
DM: constant voltage/ constant current status
EA: network distribution page
DN: screen brightness
EB: control center
3.2.3 APP Operation
3.2.3.1 Network Distribution
Connect Wi-Fi for the first time, please insert the WiFi board to the right place,
then power on RD6012P, you will see the blue LED blinks once. Set the
communication interface to WIFI, restart RD6012P,
then place the RD6012P and the mobile phone close
to the 2.4G router (the mobile phone must also be
under the same 2.4G network, and the router must
disable the AP isolation function and the WMM
function).
RD6012P will wait for the phone to connect as
shown in figure 23. Press “EA” to choose Network
distribution, it will show like figure 24, then enter the
WiFi password and click INITIALIZATION. Wait about 20
seconds.
figure 23
