Turn on the “Logo”, it will display Logo first and then enter the main page when
boot RD6006. If you turn it off, you will enter the main page directly.
The system language supports Simplified Chinese, English, German and France
for the time being; the screen brightness can be set from level 0 to level 5; The
communication interface can be set to USB, Wi-Fi or TTL, USB interface is the
Micro-USB interface on the front panel interface, you can see the on the top
when communication starts. Wi-Fi interface is the Wi-Fi module inserted to the
communication interface, you can see the on the top when communication
starts (connect mobile phone by Wi-Fi, WiFi function only support connection control
in LAN), TTL is not available for the time being; When the interface is changed, you
need to reboot RD6006 to apply the modification. The baud rate can be set to
9600/19200/38400/57600/115200 under USB mode; The Baud rate under Wi-Fi is
fixed at 115200. Device address can be set from 001-255. You can set the date and
time by rotating the encoder potentiometer, the setting will be saved immediately
after modification. Please do not set a wrong time, it may cause that the date will not
be automatically accumulated. Press the encoder potentiometer to return, and the
set value will be saved automatically. Upd.R. is the refresh rate of read back voltage
and current in the main page, you can set it to low, middle and high. We add output
power limit function, when you set that, the current will be adjusted automatically to
the value which multiply by set voltage value will not exceed the power limit, so that
it can protect the input PSU, it is recommended to set the output power value at
(rated power of PSU*95%). Press encoder potentiometer to return and save the
settings.
