RIDGID DMG9015 - Getting to Know Your Digital Miter Gauge; Main Parts

5
GETTING TO KNOW YOUR DIGITAL MITER GAUGE
The digital miter gauge is a smart tool that increases efciency in woodworking projects. It was designed by a professional
woodworker for woodworkers. It sets crosscut angles and table saw blade angles from -50° to +50° with ±0.1° accuracy in
a matter of seconds. For use with all bench, portable, and stationary table saws with 1/2", 5/8", and 3/4" slots and 5/8", 3/4",
and 7/8" T-Slots with the slot depth of 3/8" or 1/2".
Main parts
Fig. 1
1
2
3
4
5
9
10
5
11
13
14
15
17
16
18
19
20
12
6
7
8
21
