Technical Specifications
Battery 2 “AAA” 1.5V batteries
Miter angle range -50° to +50°
Blade tilt angle range -50° to +50°
Accuracy ±0.1°
Optimum Operating
Temperature Range
32°F to 104°F (0°C to 40°C)
Weight 3.67 lbs ( 1.67 kg)
GETTING TO KNOW YOUR DIGITAL MITER GAUGE
1. Machined Miter Gauge head
2. Power button: press to turn on the digital miter gauge;
press again to ip the display;
3. ZERO Button: calibrates the current angle as 0.0 de-
gree.
4. LCD Screen: large LCD display with blue back lighting
for easy reading.
5. Fence-Lock Knobs: secures the miter fence to the mi-
ter gauge head; secures the stop gauges to the miter
fence.
6. Battery Compartment: for two AAA batteries.
7. Soft Grip Locking Handle: locks and unlocks the miter
gauge head.
8. Hex Wrench: used to loosen or tighten the screws on
gauge bar attachments, magnetic blade attachment
and T-slot washer.
9. Micro-adjust Gauge: designed to be used in any of the
fence grooves, it can be used as a micro adjust for the
ip stop or a positive stop gauge.
10. Flip-Stop Gauge: a multi-use gauge that can be used in
any fence groove and as a solid stop gauge.
11. Precision Stop Gauge: For accurate repetitive cuts.
12. Miter Fence: guides the workpiece for cutting at the se-
lected angle.
13. Magnetic Blade Attachment: attaches to the 1/2” miter
gauge bar for blade -tilt adjustment.
14. 1/2” Miter Gauge Bar: ts all bench, portable, and sta-
tionary tools with a standard 1/2” miter gauge slot.
15. T-slot Washer for 3/8” depth slot: ts in T-slot tables of
bench, portable, and stationary tools with a slot depth
of 3/8”.
16. 1/4” Gauge Bar Attachment: attaches to the 1/2” miter
gauge bar to t all bench, portable, and stationary table
saws with 3/4” slot.
17. 1/8” Gauge Bar Attachment: attaches to the 1/2” miter
gauge bar to t all bench, portable and stationary table
saws with 5/8” slot.
18. Batteries
19. T-slot Washer for 1/2” depth slot: ts in T-slot tables of
bench, portable, and stationary tools with a slot depth
of 1/2”.
20. Screw for Deep T-slot Washer
21. Mitered end: permits precise miter cuts close to the
end of the miter fence.
