RIDGID DP15501 - Page 39

39
Repair Parts
Parts List for RDIGID 15" Drill Press
Model No. DP15501
Figure 4
* Standard hardware item - may be purchased locally.
1
2
3
6
7
8
10
11
4
5
2
2
18
15
17
16
14
13
12
19
20
21
9
20
22
23
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
817478
820245
821861-2
826439
821880
828927
821881-1
828870
813164-6
821754
828961
Collar Rack
* Screw Hex Soc. Set
M6 x 1.0-10
Support Table
w/Indicator
Crank (Includes Set
Screw)
Tube Column
Rack
Support Column
Tray, Back
Nut Hex M5
* Screw Hex Hd.
M10 x 1.5-40
Base
Key
No.
Part No. Description
12
13
14
15
16
17
18
19
20
21
22
23
821750
817288
817290-3
821732
817777-3
817294-2
817350
817349
10251002
828871
828903
826438
* Screw Hex Soc. Set
M10 x 1.5-12
Pin Gear
Clamp Table
Screw Hex Hd.
M16 x 2.0-35
Arm Table w/Scale
Clamp Column
Gear Helical
Worm Elevation
* Screw Pan Hd Cr
M5 x 0.8-60
Tray, Front
Table
Wrench Hex 24mm
