Repair Parts
Parts List For RIDGID 12" Compound Miter Saw
Model No. MS12502
RIDGID parts are available on-line at www.ridgidparts.com
Figure 3 - Handle and Motor Assembly
Always order by Part Number - Not by Key Number
* Standard hardware item - May be purchased locally.
• WARNING: Any attempt to repair or replace electrical parts on this
unit may create a hazard unless repair is done by a qualified service
technician.
WARNING: For your safety, this miter saw is specially insulated. To
reduce the risk of electrical shock, fire or injury, use only parts identi-
cal to those identified in the parts list. Reassemble exactly as origi-
nally assembled.
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
828123
828063
820376-5
828122
828062
828059
816725
821122-1
828057
828056
828125
816768
816770
Screw Pan Hd Ty E
M5-30
Handle Carry
*Screw Pan Hd Ty TT
M4x0.7-20
Screw Pan Hd Ty E
M4-14
Handle Upper
Actuator Switch
Clamp Cord
Guard Cord
Cord w/Plug
Handle Lower
Motor
Brush
Cover Brush
Key
No
Part No. Description
14
15
16
17
18
19
20
21
22
23
24
25
26
828064
816781
828133
823271
816755-2
820376-4
813303-4
821102
828060
828061
823493
828122-1
803709-1
Cover Rear Motor
Bearing Needle
Spindle Asm
Retainer Bearing
*Screw Pan
M5 x 0.8-15
Screw Pan Hd Ty TT
M4x0.7-10
*Lockwasher M4
*Washer 4 x 9 x 0.8
Button Lock
Spring Torsion
Switch
Screw Pan Hd Ty E
M4-10
*Connector Wire
#12–#18
