40
Repair Parts
Parts List For RIDGID 12" Compound Miter Saw
Model No. MS12502
RIDGID parts are available on-line at www.ridgidparts.com
Figure 4 - Pivot Assembly
Always order by Part Number - Not by Key Number
* Standard hardware item - May be purchased locally.
n To remove this item use a 3mm hex “L” wrench.
o To remove this item use a 2mm hex “L” wrench.
‡ CAUTION: See mechanical assembly caution on page 37.
1
2
3
4
5
6
7
8
o
9
10
11
12
19
13
14
4
15
16
17
■
18
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
828066
823320
823344
828034
821421-2
828035
828107-1
828120
821063-1
828117
‡Spring Torsion
Spacer Torsion
Spring
Shaft Arm Pivot
Cap Rubber
Ring “O”
Pin Locking
Pivot
Screw Set Lock
M4 x 0.7-5
*Washer 8 x 16 x 0.5
Washer
12.5 x 22 x 2
Key
No.
Part No. Description
11
12
13
14
15
16
17
18
19
819179
818656
827488
821875-4
823742-2
828039
828040
828041-1
828170
Washer Spring
12.7 x 22 x 0.3
Nut Lock M12 x 1.75
Knob Bevel
Screw Shoulder
M6 x 23
Ball 5mm
Spring
Screw Set Lock
M6 x 1.0-10
Pin Bevel Index
* Washer 10 x 20 x 2
