Technical description of the burner
4.6 Maximum dimensions
The maximum dimensions of the flange and burner are given in
Fig. 1.
Tab. E
F
HG
A
DE
I
R
S
N
4
5
°
4
5
°
11
O
P
B
C
M
ø L
D4475
T
Fig. 1
Model A B C D E F G H I L - T M N O P R S
BS1D 234 254 295 122 112 346 230 -276 11670 174 89 210 192 66 167 140 170
BS2D 255 280 325 125.5 125.5 352 238-252 114-100 174 106 230 192 66 167 140 170
BS3D 300 345 391 150 150 390 262-280 128-110 196 129 285 216 76.5 201 160 190
BS4D 300 345 392 150 150 446 278-301 168-145 216 137 286 218 80.5 203 170 200
