5.10.3 Gas train
Approved according to standard EN 676 and provided separately
from the burner. For its adjustment see the enclosed instructions.
5.10.4 Gas pressure
Tab. I indicates the pressure drops of the combustion head and
gas butterfly valve, on the basis of the burner operating output.
The values shown in Tab. I refer to:
- Natural gas G 20 NCV 9.45 kWh/Sm
3
(8.2 Mcal/Sm
3
)
- Natural gas G 25 NCV 8.13 kWh/Sm
3
(7.0 Mcal/Sm
3
)
Column 1
Combustion head pressure drop.
Gas pressure measured at test point M2)(Fig. 16 on page 20),
with:
• combustion chamber at 0 mbar;
• burner working at maximum output
To calculate the approximate output at which the burner oper-
ates:
- subtract the pressure in the combustion chamber from the
pressure of the gas at test point M2)(Fig. 16 on page 20).
- Find, inTab. I related to the burner concerned, the pressure
value closest to the result of the subtraction.
- Read the corresponding output on the left.
Example with G 20 natural gas for BS2D:
Maximum output operation
Gas pressure at test point M2)(Fig. 16) = 10 mbar
Pressure in combustion chamber = 2.2 mbar
10 - 2.2 = 7.8 mbar
A pressure of 7.8 mbar, column 1, corresponds in Tab. I to an out-
put of 91 kW.
This value serves as a rough guide; the effective output must be
measured at the gas meter.
Tab. I
To calcula te
the required gas pressure at test point M2)(Fig. 16
on page 20), with the maximum modulating output at which you
want the burner to operate having been fixed:
- find the nearest output value in Tab. I for the burner in ques-
tion.
- Read on the right, column 1, the pressure at the socket
M2)(Fig. 16 on page 20).
- Add this value to the estimated pressure in combustion
chamber.
Example with G 20 natural gas for BS2D:
Operating at the desired maximum output: 91 kW
Gas pressure at an output of 91 kW = 7.8 mbar
Pressure in combustion chamber = 2.2 mbar
7.8 + 2.2 = 10 mbar
pressure required at the test point M2)(Fig. 16 on page 20).
DANGER
Disconnect the electrical power using the main
switch.
Check that there are no gas leaks.
Pay attention when handling the train: danger of
crushing of limbs.
Make sure that the gas train is properly installed
by checking for any fuel leaks.
The operator must use the required equipment
during installation.
WARNING
The data of thermal output and combustion
head gas pressure are related to full open (90°)
gas butterfly valve.
kW
p (mbar)
G 20 G 25 G 31
BS1D
19 0.6 0.84 2.4
23 0.9 1.26 2.9
26 1.1 1.54 3.6
30 1.5 2.1 4.9
34 2.1 2.94 6.4
37 2.6 3.64 7.6
41 3.3 4.62 9.2
45 4.3 6.02 10.8
48 2.2 7.28 11.8
52 6.5 9.1 13
BS2D
49 2.8 3.92 3.8
54 3.2 4.48 4.8
58 3.6 5.01 5.5
63 4.1 5.74 6.3
68 4.7 6.58 7
72 5.1 7.14 7.5
77 5.8 8.12 8.2
82 6.5 9.1 9
86 7.0 9.8 9.8
91 7.8 10.92 11
BS3D
79 2.0 2.8 3.8
92 2.6 3.64 4.6
105 3.3 4.62 5.6
118 4.2 5.88 6.6
131 5.1 7.14 7.7
143 6.1 8.54 8.7
156 7.3 10.22 9.9
169 8.7 12.18 11.1
182 10.2 14.28 12.3
195 11.9 16.66 13.5
BS4D
140 4.1 5.74 3.5
152 4.6 6.44 3.9
164 5.2 7.28 4.3
177 5.9 8.26 4.6
189 6.6 9.24 4.9
201 7.3 10.22 5.3
213 8.1 11.34 5.8
226 9.0 12.6 6.6
238 9.8 13.72 7.6
250 10.8 15.12 9
