Riello Condexa Pro3 Series User Manual

7
TECHNICAL FEATURES
SYSTEM COMPONENTS
10
14
24
16 17
1
2
3
4
7
8
11
12
19
22
23
13
5
6
9
15
18
20
21
Figure 4
1 Frame
2 Control panel
3 Exchanger
4 Air inlet pipe
5 Fan
6 Return detection tap
7 Pump (or 2-way valve)
8 Unit Switch
9 Return probe
10 Exhaust ue probe
11 Water differential pressure switch
12 Gas valve
13 Ignition electrode
14 Automatic vent valve
15 Safety thermostat
16 Gas cock
17 Venturi tubes
18 Flow probe
19 Exhaust ue duct
20 Gas manifold
21 Water ow manifold
22 Condensate manifold
23 Water return manifold
24 Smoke-exhaust ue non-return valve
