8
DISPLAY PANEL VIEW
“SEL” button (Select)
Load level indicator
“ON” button
Configuration area
“STAND-BY” button
Maintenance request
Regular operation
Timer
Mains operation
Measurement display area
Battery operation
Stand-by / alarm
AVR active
EnergyShare
Battery charge indicator
