MSO2000A/DS2000A User’s Guide
XIX
Chapter 16 Remote Control Introduce how to control the oscilloscope
remotely.
Chapter 17 Troubleshooting Introduce how to deal with common failures
of the oscilloscope.
Chapter 18 Specifications Provide the specifications and general
specifications of the oscilloscope.
Chapter 19 Appendix Provide common information such as options
and accessories.
Format Conventions in this Manual:
1. Key
The key at the front panel is denoted by the format of “Key Name (Bold) + Text
Box”. For example, Utility denotes the “Utility” key.
2. Menu Softkey
The menu softkey is denoted by the format of “Menu Word (Bold) + Character
Shading”. For example, System denotes the “System” menu softkey under
Utility.
3. Operation Step
The next step of operation is denoted by an arrow “”. For example, Utility
System denotes pressing Utility at the front panel and then pressing System.
4. Knob
Label Knob
HORIZONTAL SCALE
Horizontal Scale Knob
HORIZONTAL POSITION
Horizontal Position Knob
VERTICAL SCALE
Vertical Scale Knob
VERTICAL POSITION
Vertical Position Knob
TRIGGER LEVEL
Trigger Level Knob
Multifunction Knob
