RIGOL Chapter 14 Store and Recall
14-4 MSO2000A/DS2000A User’s Guide
After a USB storage device is connected, press at the front panel to
quickly save the current screen image under the root directory of the USB
storage device.
5. CSV
Save the waveform data displayed on the screen or of the specified channels in
external memory in a single “*.csv” file. You can specify the file name and the
saving directory and save the corresponding parameter file (*.txt) under the
same directory using the same file name. The recall of CSV and parameter files
is not supported.
After selecting this type:
Press DataDepth to select “Displayed” or “Maximum”. After selecting
“Maximum”, press Channel to select the desired channel (Note: Only channels
currently enabled can be selected).
Press Para.Save to enable or disable the parameter save function.
Press Sequence to select whether to add sequence numbers for the waveform
points in the CSV file. You can select “ON” or “OFF”.
