RIGOL Chapter 10 Utility Functions and System Settings
DG4000 User's Guide
10-16
Power On Setting
Set the configuration to be used when the instrument is powered on the next time
to "Default" or "Last". The default setting is "Default".
 Last: include all the system parameters, except output configuration, clock
source.
 Default: denote the factory default except some parameters (such as:
Language).
Press Utility  System  PowerOn to select the desired configuration type.
This setting is stored in non-volatile memory and will not be influenced by "Preset".
Power Setting
Set the start-up mode after the generator is powered on to "Auto" or "Manual" and
the default is "Auto".
 Auto: the instrument starts automatically after power-on.
 Manual: users need to press the power switch at the front panel to start the
instrument after power-on.
Press Utility  System  PowerSet to select the desired type.
Clock Source
DG4000 provides an internal 10MHz clock source and can receive the external
clock source from the [10MHz In/Out] connector at the rear panel. It can also
output the internal clock source from the [10MHz In/Out] connector for other
devices.
Press Utility  System  Clk Src to select "Int" or "Ext". The default is "Int". If
"Ext" is selected, the instrument will detect whether a valid external clock signal is
input from the [10MHz Out/In] connector at the rear panel. If no valid clock
