Chapter 2 Basic Waveform Output RIGOL
DG4000 User's Guide
To Set the Start Phase
The setting range of start phase is from 0° to 360° and the default is 0°.
The start phase displayed on the screen is the default value or the phase
previously set. When the instrument function is changed, the new function will still
use this phase.
Press Start Phase to highlight the softkey. At this point, use the numeric
keyboard to input the start phase value and select the unit "°" from the pop-up
unit menu or use the direction keys and knob to modify the current value. For the
input method of phase value, refer to the introduction in "
Parameter Setting
Method".
To Next Page
