select the submenus under this menu and then press down the
knob to select the current submenu. It can also be used to modify
parameters and input filename. In addition, for DS1000Z-S
models oscilloscope, in the source interface, press the
corresponding menu softkey and then press the knob; the
numeric keyboard will pop-up on the screen and you can input
the desired parameter value and unit directly using this knob.
MENU
Measure: press this key to open the measurement setting menu.
You can set the measurement setting, all measure, statistic
function etc.
Press MENU at the left of the screen to switch the measurement
menus of 24 waveform parameters. Then, press down the
corresponding menu softkey to quickly realize one-key
measurement and the measurement result will be displayed at the
bottom of the screen.
Acquire: press this key to enter the sample setting menu to set
the acquisition mode, Sin(x)/x and memory depth of the
oscilloscope.
