DS1000Z Quick Guide
22
The following symbols might be displayed in the menu:
Denote that
at the front panel can be used to
select parameter items. The backlight of
turns on
when parameter selection is valid.
Denote that you can use
to adjust the parameter
and then press down
to select the parameter.
Denote that press
to input desired paramrter
values directly using the pop-up numeric keyboard.
The backlight of
turns on when parameter input is
valid.
Denote that the current menu has several options.
Denote that the current menu has a lower level menu.
Press this key to return to the previous menu.
The number of the dots denotes that the number of
the pages the current menu has.
To Use the Security Lock
If needed, you can use the security lock (please buy it yourself) to
lock the oscilloscope to a fixed location. The method is as follows,
align the lock with the lock hole and plug it into the lock hole
vertically, turn the key clockwise to lock the oscilloscope and then
pull the key out.
Figure 12 To Use the Security Lock
Note: please do not insert other articles into the security lock hole
to avoid damaging the instrument.
Security Lock Hole
