To Use the Built-in Help System
The help system of this oscilloscope provides instructions for all
the function keys (including menu keys) at the front panel. Press
Help to open the help interface and press again to close the
interface. The help interface mainly consists of two parts. The left
is “Help Options” and you can use “Button” or “Index” mode to
select. The right is “Help Display Area”.
Figure 13 Help Information
Button:
Default mode. In this mode, you can press the button (except the
power key
, the knob and the menu page up/down key
/ ) at the front panel directly to get the corresponding help
information in the “Help Display Area”. Use
to select “To
Index” and then press the knob to switch to Index mode.
Index:
In this mode, use
to select the item that needs to get help (for
example, “Band Width”). Press the knob to get the corresponding
help information in the “Help Display Area”. Use
to select “To
Button” and then press the knob to switch to Button mode.
Help Options Help Display Area
To Next Page
