RIGOL Chapter 1 Disassemble and Assemble
1-6 MSO1000Z/DS1000Z Service Guide
Tip:
 Pay attention to the connecting positions of the power cord and fan cable
before removing them to avoid incorrect connection or incomplete
connection when assembling the instrument.

Check whether the screen line and the keyboard cable on the main board are
correctly installed before assembling the rear metal cover.

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
