RIGOL Chapter 1 Disassemble and Assemble
1-10 MSO1000Z/DS1000Z Service Guide
Tip:
 Pay attention to the connecting positions of the keyboard cables and screen
line connected to the main board before removing them to avoid incorrect
connection or incomplete connection when assembling the instrument.
 When assembling the ke
yboards and LCD, pass the left keyboard cable, main
keyboard cable and screen line through the corresponding holes on the front
metal plate, fasten the main board and then insert the cables to the
corresponding positions.

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
