Rigol DS1202Z-E Quick Guide

RIGOL
DS1000Z-E Quick Guide
17
12. Analog Channel Label/Waveform
Different channels are marked with different colors and the colors of the channel
label and waveform are the same.
13. CH2 Vertical Scale
 Display the voltage value per grid of CH2 waveform vertically.
 Use VERTICAL SCALE to modify this parameter.
 The following labels will be displayed according to the current channel
setting: channel coupling (e.g. ) and bandwidth limit (e.g. ).
14. Message Box
Display prompt messages.
15. Notification Area
Display sound icon and USB disk icon.
 Sound Icon: Press Utility  Sound to enable or disable the sound. When
the sound is enabled, will be displayed; when the sound is disabled,
will be displayed.
 USB Disk Icon: when a USB disk is detected, will be displayed.
16. Operation Menu
Press any softkey to activate the corresponding menu.
The following symbols might be displayed in the menu:
Denote that you can rotate the multifunction knob to modify
parameters. The backlight of turns on during the parameter
modification.
Denote that you can rotate to select the desired item, the item
currently selected is displayed in blue, press down the knob to enter the
corresponding menu. The backlight of is constant on after menus
with this symbol are selected.
Denote that press to input desired paramrter values directly using
the pop-up numeric keyboard. The backlight of is constant on after
menus with this symbol are selected.
Denote that the current menu has several options.
Denote that the current menu has a lower level menu.
Press this key to return to the previous menu.
The number of the dots denotes that the number of the pages the
current menu has.

Rigol DS1202Z-E Specifications

General

Type	Tabletop
Product type	Digital sampling oscilloscope
Bandwidth	200 MHz
Sampling rate	500 MS/s
Frequency range	0 - 0.001 MHz
Channels quantity	2 channels
Vertical resolution	8 bit
Minimum time base setting (per division)	4 ns
Minimum vertical sensitivity (per division)	1 mV
Display type	LCD
Display diagonal	7 \
Display resolution	800 x 480 pixels
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	50 W
Operating temperature (T-T)	0 - 50 °C
Package weight	3500 g

Weight and Dimensions

Depth	122.4 mm
Width	313.1 mm
Height	160.8 mm
Weight	2900 g
