RIGOL 5 To Trigger the Oscilloscope
5-30 DS6000 User’s Guide
Symbol), MTS (Media Access Test Symbol) and WUP (Wakeup Pattern) of
FlexRay bus.
 ERROR: trigger when error occurs to FlexRay bus, including header CRC error
and frame CRC error.
 TSS: trigger on the transmission start sequence of FlexRay bus.
Note: As the occurrence probability of specified FlaxRay frame is very low, when the
trigger condition is "Frame", it is recommended to set the oscilloscope to "Normal"
trigger mode to prevent the instrument from triggering automatically when waiting
for the specified frame. The same goes for "Error" trigger condition. What’s more,
the trigger holdoff might need to be adjusted to view a specified error when multiple
FlaxRay errors occur at the same time.
Trigger Mode:
Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto,
normal or single. The corresponding status light of the current trigger mode turns on.
Trigger Level:
Use TRIGGER
LEVEL to modify the level. For details, please refer to the
description of Trigger Level on page
5-8.
