Rigol DS6000 Series User Manual

RIGOL 11 Display Control
11-2 DS6000 User’s Guide
To Select the Display Type
Press DISP  Type to set the waveform display mode to "Vectors" or "Dots".
 Vectors: the sample points are connected using lines and displayed. Normally,
this mode can provide the most vivid waveform to view the steep edge of the
waveform (e.g. square waveform).
 Dots: display the sample points directly. You can directly view each sample point
and use the cursor to measure the X and Y values of the sample point.
DISP
