Rigol DS6000 Series User Manual

12 Store and Recall RIGOL
DS6000 User’s Guide 12-5
Internal Store and Recall
Internal store and recall support "Traces", "Waveforms" and "Setups" in Storage. In
the following part, "Traces" are taken as an example for illustration.
1. Save the specified type of file in internal memory.
1) Connect the signal to the oscilloscope and obtain stable display.
2) Press SAVE  Storage to select "Traces" and press Save to turn on the
interface as shown in Figure a. use to select " Local Disk" and press
to turn on the local disk (Figure b).
Figure a
