RIGOL 5 To Trigger the Oscilloscope
5-32 DS6000 User’s Guide
Trigger Mode:
Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto,
normal or single. The corresponding status light of the current trigger mode turns on.
Trigger Level:
Use TRIGGER
LEVEL to modify the level. For details, please refer to the
description of Trigger Level on page
5-8.
