Rigol DS6000 Series User Manual

6 To Make Measurements RIGOL
DS6000 User’s Guide 6-41
specified points (the crossing points of the cursors) of the waveforms of
CH3 and CH4 respectively.
2. Adjust the positions of the X/Y cursors
When the cursor type is "X", you can adjust the positions of the X cursors.
 Adjust cursor A: press CursorA and use to adjust the position of cursor
A. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
 Adjust cursor B: press CursorB and use to adjust the position of cursor
B. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
 Adjust cursors A and B at the same time: press CursorAB and use to
adjust the positions of cursors A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable ranges are limited within the screen.
When the cursor type is "Y", you can adjust the positions of the Y cursors.
 Adjust cursor A: press CursorA and use to adjust the position of cursor
A. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
 Adjust cursor B: press CursorB and use to adjust the position of cursor
B. During the adjustment, the measurement result will change accordingly.
The adjustable range is limited within the screen.
 Adjust cursors A and B at the same time: press CursorAB and use to
adjust the positions of cursors A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable ranges are limited within the screen.
