Rigol DS6000 Series User Manual

RIGOL 12 Store and Recall
12-18 DS6000 User’s Guide
Channel Invert OFF
Vertical Scale Coarse
Channel Unit V
Acquisition Setting (ACQ)
Acquisition Mode Normal
Sampling Mode Real Time
Memory Depth Auto
Anti-Aliasing OFF
Trigger Setting (TRIGGER)
Trigger Type Edge
Source CH1
Slope Rising Edge
Trigger Mode Auto
Trigger Coupling DC
Trigger Holdoff 100 ns
Display Setting (DISP)
Display Type Vectors
Persistence Time Min
Waveform Intensity 50%
Screen Grid
Brightness 50%
Menu Display Infinite
Cursor Setting (CURS)
Mode OFF
Manual
Cursor Type X-Y
Source CH1
Select Cursor X
Time Unit s
Vertical Unit The unit of the signal source
Horizontal Positions of the X Cursors
CursorA -4*1 μs
CursorB 4*1 μs
Vertical Positions of the Y Cursors
CursorA 2*1 V
CursorB -2*1 V
