Rigol DS6000 Series

RIGOL 16 Specifications
16-2 DS6000 User’s Guide
Input
Number of Channels DS6XX4: four channels
DS6XX2: two channels
Input Coupling DC, AC, GND
Input Impedance (1 MΩ ± 1%) || (13 pF ± 3 pF)
or 50 Ω ± 1.5%
Probe Attenuation
Coefficient
0.01X to 1000X, in 1-2-5 step
Maximum Input
Voltage (1MΩ)
Maximum Input Voltage of the Analog Channel
CAT I 300 Vrms, CAT II 100 Vrms,
Transient Overvoltage 1000V pk
with RP2200 10:1 probe: CAT II 300 Vrms
with RP3300A 10:1 probe: CAT II 300 Vrms
with RP3500A 10:1 probe: CAT II 300 Vrms
with RP5600A 10:1 probe: CAT II 300 Vrms
Horizontal
Timebase Scale DS606X: 1 ns to 1000 s
DS610X: 500 ps to 1000 s
Deviation Between
Channels
±0.5 div*minimum time base
Max Recording Length 140 Mpts
Timebase Accuracy ≤±4 ppm
Clock Drift ≤±2 ppm/year
Delay Range Pre-trigger (negative delay): memory depth/sample rate
Post-trigger (positive delay): 1 s to 100,000 s
Timebase Mode Y-T, X-Y, Roll, Delayed Sweep
Number of X-Ys 2 paths simultaneously (four-channel models)
Waveform Capture
Rate
[1]
150,000 wfms (vector display); 180,000 wfms (dots
display)
Zero Point Offset ±0.5 div*minimum time base
