16 Specifications RIGOL
DS6000 User’s Guide 16-7
Math Operation
Waveform Operation A+B, A-B, A×B, A÷B, FFT,
Editable Advanced Operation,
Logic Operation
FFT Window Function Rectangle, Hanning, Blackman, Hamming
FFT Display Split, Full Screen
FFT Vertical Scale Vrms, dB
Anti-aliasing OFF
Logic Operation AND, OR, NOT, XOR
Math Function Intg, Diff, Lg, Exp, Sqrt, Sine, Cosine, Tangent
Number of Buses for
Decoding
2
Decoding Type Parallel (standard), RS232/UART (option), I2C (option) ,
SPI (DS6XX4 option), CAN (option), FlaxRay (option)
Display
Display Type 10.1 inches (257 mm) TFT LCD display
Display Resolution 800 Horizontal ×RGB×480 Vertical Pixel
Display Color 160,000 Color
Persistence Time Minimum, 50 ms, 100 ms, 200 ms, 500ms, 1 s, 2 s, 5 s,
10 s, 20 s, Infinite
Display Type Dots, Vectors
Real-time Clock Time and Date (user adjustable)
I/O
Standard Ports Dual USB HOST, USB device, LAN, VGA Output, 10 MHz
Input/Output, Aux output (TrigOut, Fast, GND, PassFail)
Printer Compatibility PictBridge
