RIGOL Chapter 2 Command System
2-212 MSO7000/DS7000 Programming Guide
:TRIGger:SPI:CS
Syntax
:TRIGger:SPI:CS <source>
:TRIGger:SPI:CS?
Description
Sets or queries the source channel of the CS line when the trigger condition of SPI
is set to CS.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D
11|D12|D13|D14|D15|CHANnel1|CHANnel2
|CHANnel3|CHANnel4}
CHANnel3
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13,
D14, D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:SPI:CS CHANnel2
/*Sets source channel of the CS line when the trigger condition of SPI is set to CS
to CH2.*/
:TRIGger:SPI:CS? /*The query returns CHAN2.*/
