RIGOL Chapter 2 Command System
2-188 MSO7000/DS7000 Programming Guide
:TRIGger:DELay
Command List:
 :TRIGger:DELay:SA
 :TRIGger:DELay:SLOPa
 :TRIGger:DELay:SB
 :TRIGger:DELay:SLOPb
 :TRIGger:DELay:TYPE
 :TRIGger:DELay:TUPPer
 :TRIGger:DELay:TLOWer
 :TRIGger:DELay:ALEVel
 :TRIGger:DELay:BLEVel
:TRIGger:DELay:SA
Syntax
:TRIGger:DELay:SA <Source>
:TRIGger:DELay:SA?
Description
Sets or queries the trigger source of Source A in Delay trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D1
1|D12|D13|D14|D15|CHANnel1|CHANnel2|CH
ANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:DELay:SA CHANnel2 /*Sets trigger source A to CH2.*/
:TRIGger:DELay:SA? /*The query returns CHAN2.*/
:TRIGger:DELay:SLOPa
Syntax
:TRIGger:DELay:SLOPa <slope>
:TRIGger:DELay:SLOPa?
Description
Sets or queries the edge type of Edge A in Delay trigger.
Parameter
Name
Type
Range
Default
<slope>
Discrete
{POSitive|NEGative}
POSitive
Return
Format
The query returns POS or NEG.
Example
:TRIGger:DELay:SLOPa NEGative /*Sets the type of Edge A to Falling Edge.*/
:TRIGger:DELay:SLOPa? /*The query returns NEG.*/
