Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-35
:BUS<n>:IIS (Option)
The :BUS<n>:IIC commands are used to set relevant parameters for I2S decoding.
Command List:
 :BUS<n>:IIS:SOURce:CLOCk
 :BUS<n>:IIS:SOURce:DATA
 :BUS<n>:IIS:SOURce:WSELect
 :BUS<n>:IIS:ALIGnment
 :BUS<n>:IIS:CLOCk:SLOPe
 :BUS<n>:IIS:RWIDth
:BUS<n>:IIS:SOURce:CLOCk
Syntax
:BUS<n>:IIS:SOURce:CLOCk <source>
:BUS<n>:IIS:SOURce:CLOCk?
Description
Sets or queries the clock source of the I2S decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D
11|D12|D13|D14|D15|CHANnel1|CHANnel2
|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:BUS1:IIS:SOURce:CLOCk D0 /*Sets the clock source of the I2S decoding to D0.*/
:BUS1:IIS:SOURce:CLOCk? /*The query returns D0.*/
:BUS<n>:IIS:SOURce:DATA
Syntax
:BUS<n>:IIS:SOURce:DATA<source>
:BUS<n>:IIS:SOURce:DATA?
Description
Sets or queries the data source of the I2S decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D
11|D12|D13|D14|D15|CHANnel1|CHANnel2
|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:BUS1:IIS:SOURce:DATA D0 /*Sets the data source of the I2S decoding to D0.*/
:BUS1:IIS:SOURce:DATA? /*The query returns D0.*/
