RIGOL Chapter 2 Command System
2-52 MSO7000/DS7000 Programming Guide
:CURSor:MANual:SOURce
Syntax
:CURSor:MANual:SOURce <source>
:CURSor:MANual:SOURce?
Description
Sets or queries the channel source of the manual mode of cursor measurement.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4|
MATH1|MATH2|MATH3|MATH4|LA|NONE}
CHANnel1
Remarks
 Only the currently enabled channel can be selected as the channel source.
 When LA is selected, the cursor type cannot be set to Y (:CURSor:MANual:TYPE).
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4, MATH1, MATH2, MATH3, MATH4,
LA, or NONE.
Example
:CURSor:MANual:SOURce CHANnel2 /*Sets the channel source to CH2.*/
:CURSor:MANual:SOURce? /*The query returns CHAN2.*/
:CURSor:MANual:TUNit
Syntax
:CURSor:MANual:TUNit <unit>
:CURSor:MANual:TUNit?
Description
Sets or queries the horizontal unit in the manual mode of cursor measurement.
Parameter
Name
Type
Range
Default
<unit>
Discrete
{SECond|HZ|DEGRee|PERCent}
SECond
Remarks
 SECond: in the measurement results, AX, BX, and △ X are expressed in "s"; 1/△X in
"Hz".
 HZ: in the measurement results, AX, BX, and △ X are expressed in "Hz"; 1/△X in
"s".
 DEGRee: in the measurement results, AX, BX, and △ X are expressed in "°".
 PERCent: in the measurement results, AX, BX, and △ X are expressed in
percentage.
Return
Format
The query returns SEC, HZ, DEGR, or PERC.
Example
:CURSor:MANual:TUNit DEGRee /*Sets the horizontal unit to DEGRee.*/
:CURSor:MANual:TUNit? /*The query returns DEGR.*/
