RIGOL Chapter 2 Command System
2-58 MSO7000/DS7000 Programming Guide
:CURSor:TRACk:SOURce2
Syntax
:CURSor:TRACk:SOURce2 <source>
:CURSor:TRACk:SOURce2?
Description
Sets or queries the channel source of Cursor B in the track mode of cursor measurement.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4|
MATH1|MATH2|MATH3|MATH4|NONE}
CHANnel1
Remarks
Only the currently enabled channel can be selected as the channel source.
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4, MATH1, MATH2, MATH3, MATH4, or
NONE.
Example
:CURSor:TRACk:SOURce2 CHANnel2 /*Sets the channel source to CH2.*/
:CURSor:TRACk:SOURce2? /*The query returns CHAN2.*/
:CURSor:TRACk:CAX
Syntax
:CURSor:TRACk:CAX <ax>
:CURSor:TRACk:CAX?
Description
Sets or queries the horizontal position of Cursor A in the track mode of cursor
measurement.
Parameter
Name
Type
Range
Default
<ax>
Integer
0 to 999
400
Remarks
The horizontal and vertical position of the cursor is defined by the screen pixel
coordinate. The range of the screen pixel coordinate is from (0,0) to (999,479).
Wherein, (0,0) is a location at the upper-left corner of the screen, and (999,479) is a
location at the lower-right corner of the screen. The pixel range in the horizontal
direction is from 0 to 999, and the pixel range in the vertical direction is from 0 to 479.
Return
Format
The query returns an integer ranging from 0 to 999.
Example
:CURSor:TRACk:CAX 200 /*Sets the horizontal position of Cursor A to 200.*/
:CURSor:TRACk:CAX? /*The query returns 200.*/
