Rigol DS8000-R Series Quick Guide

RIGOL
DS8000-R Quick Guide 7
English
Figure 1 Front Panel
Table 1 Front Panel Description
No.
Description
No.
Description
1
RUN/STOP Key
2
LAN Interface Indicator
3
Acq Indicator
4
50 Ω Indicator
5
USB HOST Interface
6
Probe Compensation Signal
Output Terminal/Ground
Terminal
7
1 MΩ Indicator
8
Analog channel input
terminals
9
Power Key
10
Force Key (used to initiate a
trigger forcibly)
Figure 2 Rear Panel
1 2 3 4 5
10 9 8 7 6
3 4 5 6 7
16 15 14
2 1 8 9 10 11
16 15 14
