Chapter 1 Disassembly and Assembly RIGOL
MSO8000 Service Guide 1-5
Disassemble the Front Bracket
Figure 1-3 Disassemble the Front Bracket
Part Description:
① 2 front brackets
Disassembly Step:
Take off the front brackets gently.
