Prism Printer Specifications
Item Description
Printing Speed 0.65 inches/second @ 300 x 300 dpi, typical
0.45 inches/second @ 300 x 600 dpi, typical
Printing Direction Images are printed from a top to bottom orientation as the media is moving
out of the machine.
Printing Modes Single-pass (standard) and double-pass (monocolor ribbon only) for
improved print quality on some media types.
Print Quality 300x300 or 300x600 dpi (11.8 dots per mm)
Media Types 120mm CD and DVD media with thermal protective layers
Standard Ribbon Color Black, Red, and Blue monocolor ribbons
Multi-Color Ribbon 3-color (CMY) panel ribbon
Ribbon Capacity Monochrome black = 2100 discs
Monochrome red = 2100 discs
Monochrome blue = 2100 discs
3-color panel = 500 discs
Physical Properties 6.0" H x 8.5" W x 14.0" D
(15.24 cm x 21.59 cm x 35.56 cm)
18 pounds (8.2 kg)
Interface USB 1.0, Parallel, Serial (USB supported with Windows 2000, Windows XP,
and Windows Server 2003)
Power 100-240 VAC, 50-60 Hz, 1.10–0.55 Amps auto ranging
Operating Temperature 60° F to 90° F (15.5° C to 35° C)
Relative Humidity 30% to 80% non-condensing
System Requirements Pentium or Greater with min 64MB RAM
Windows XP requires 128 MB
Technical Support and Product Updates
Support for the Prism printer is available through your authorized reseller.
- Important! Register your Prism online or complete and return the registration card so Rimage can
notify you of upgrades as they become available.
n
indicate situations that could result in bodily injury to personnel operating or maintaining the equipment.
Safety Information
This manual and the indications on the product allow proper and safe operation. The indication marks below
help protect you and other persons from injury, and equipment from damage.
Warning! According to ANSI (American National Standards Institute) standards, a warning is used to
