8
9
If you’re wiring your Video
Doorbell, feed your doorbell
wires through the hole in the
mounting bracket first.
Drive the screws into your
wall (or into the anchors, if
installed) until they are flush
with the mounting bracket.
Connect
the wires.
(optional)
Connect your doorbell wires to the
screws on the rear of your Video
Doorbell. It doesn’t matter which
wire connects to each screw.
Install the
mounting
bracket.
(continued)
Your Video Doorbell is compatible with doorbell systems
supplying 8-24 volts AC, 50mA, at 50 or 60Hz, 40VA max.
Do not connect to a DC transformer, halogen or lighting
transformer, or intercom.
Ring_PACK_DoorRVD1_G2_UserManual_v5.indd 8-9 3/5/20 2:10 PM
