Infinity REU-V3232W /HD250E REU-V3232WC - 22 - Issue 1 - 8/09/03 ©Rinnai
14. Fault Finding
If there is a fault with the appliance, and controllers are installed, a numerical fault code may appear on the
digital display controller. If controllers are not installed, one may be fitted to find out the fault code. Fault
finding without controllers (and thus fault codes) is possible but more time consuming.
To diagnose and rectify faults, the Fault Finding Table is used as illustrated below:
Fault Finding Table
Describes possible faults
and error codes.
(page 23)
Operational
Flow Chart
(page 14)
Component Circuit Value Table
Summarises running and standby electrical values
for all components.
(page 25)
Wiring Diagram
(page 19)
Maintenance
Monitor / Error
History
Provides accumulated
number of startups,
combustion time, history
of operational faults and
readout of electrical values
whilst unit operational.
(page 37)
Component and
Circuit Check
Procedures
Detailed information on
how to check all
components.
(page 26)
Dismantling for
Service
Detailed information on
how to remove and
replace components.
(page 43)
