Rinnai Australia - 11 - Solar Split Systems Operating / Installation Manual - Version 8 - 18/10/10
Table 3 - Model Numbers and Specifications
CHARACTERISTICS
Enduro / Equinox
(SP200A) or
(SP200A FTC)
Excelsior
(EXT OR EXT FTC)
E-FROST
(HPFTC- 8-10)
TYPE
Flat plate Flat plate
Flat Plate /
Heat Pipe
- Waterways Copper Copper Copper
- Absorber Aluminium Copper Aluminium
- Selective Surface High Performance Sputtered Titanium Oxide High Performance
Maximum Operating
Pressure
Casing Material
Overall Dimensions
(L x W x H) (mm)
1940 x
1025 x
80
1964 x
1047 x
81
1940 x
1025 x
80
Weight empty
(STD/FTC) (kg).
33 / 35 35 / 38 34
Water volume (Litres) 1.3 1.5 0.6
Number risers
810
10
Potential Solar Output at
PTR relief conditions (kW)
- 1 Collector (mm) 1940 x 1025 1940 x 1047 1940 x 1025
- 2 Collectors (mm) 1940 x 2130 1940 x 2174 1940 x 2130
- 3 Collectors (mm) 1940 x 3235 1940 x 3301 1940 x 3235
Frost Protection to -12°C.
Power must be on at the
pump and the controller
must be in low temperature
mode
(refer page 19).
MODEL NUMBERS AND SPECIFICATIONS
CONSTRUCTION
850 kPa
Aluminium
1.25
Approximate Roof space Required: Length x Width
Frost Protection
* Standard version - no frost protection
FTC Version Frost Protection to -5°C
* FOR MORE INFORMATION ON FROST PROTECTION
REFER TO WARRANTY BOOKLET
To Next Page
