Rinnai Australia - 24 - Solar Split Systems Operating / Installation Manual - Version 8 - 18/10/10
STANDARD INSTALLATION
Collector Mounting Component Pre Assembly for a Standard Installation
Assemble the collector rail components as shown in Figure 18 below.
Only loosely attach the collector retainers to the rails.
Figure 18 - Collector Mounting Components
This installation is not suitable for use in cyclonic areas. For further details, please
contact your local Rinnai Solar distributor.
NOTE
MOUNTING RAIL
COLLECTOR SUPPORT STRAPS
COLLECTOR SUPPORT STRAPS
COLLECTOR RETAINERS
M6 BOLT, NUT &WASHER
COLLECTOR RETAINERS
M6 BOLT, NUT &WASHER
MOUNTING RAIL
INSTALLATION OF SOLAR COLLECTORS
