Rinnai SUNMASTER - Page 37

Rinnai Australia - 35 - Solar Split Systems Operating / Installation Manual Version 8-18/10/10
Sunmaster SG175 or SG215 with SGPKIT
Items Supplied with Cylinder Items Supplied in SGPKIT (cont…)
1
1
PTR Valve 92501190
1
Adaptor R ¾ x Rp ½
3
3
Nipple R ¾
11
1
Pump & Controller Assembly 39001735
includes:
x 2 x ½” Kinco nut & olive
x flow control valve 11001033
x non return valve 27801711
x Temperature sensor lead 31002710
x Pump 30001703
x Control Box 31002703
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly
(39001735), but shown separately
for clarity in diagrams 31002710
16
2
Gas Booster Mounting Brackets
1 x tabs bent
26601098
1 x tabs unbent 26601096
Items Supplied in SGPKIT
13
2
Elbow ¾ Rp x ¾ G flexi 21201012
5
1
¾ Kinco Olive 33001011
14
2
Fibre Washer ¾ 17401008
6
1
¾ Kinco Nut 16801018
7
1
Copper Tee 11603936
15
1
Insulated Flexi Pipe 890 mm 11601070
8
2
½ Kinco Olive
33001012
(*1 not needed)
- 12
Screws 22601048
9
2
½ Kinco Nut 16801012
(*1 not needed)
- 3
Cable Ties 39601036
* 2
Nipples 17201003
10
1
Insulated Copper
Extension Pipe
11603348
-
1
Operation and
Installation Manual
15401030
-
1
Booster and Pump Mounting
Instruction Sheet
15401031
-
1 Warranty booklet
15401024
- 1
Saddle Clamp 27201015
-
1 RECS form
15401023 - 1 Standardsmark Sticker 15802091
*ff * f
INSTALLATION & MAINTENANCE - GAS BOOSTED SYSTEMS
